$1050.00 - 700.00 / Piece/Pieces
| 1 Piece/Pieces | (Min. Order) | |
| Size: | ||
| Material: | ||
| pressure: | ||
| Option: | ||
| FANOMEZANA: |
|
|
| Share: |
|
|
Brand: Cepai
Karazana: Globe Valves
Fanohanana Ny Fanohanana: Oem
Toerana Niaviany: Shina
Hafanana Antonony: Hafanana ara-dalàna
Fahefana: Pneumatika
Flow Medium: mandatsa-dranomaso, Rano, SOLIKA
FIRAFITRA: fanaraha-maso
| Quantity（Piece/Pieces） | 1 ~ 10 | >10 |
| Est. Time（days) | 20 | To be negotiated |
Raha vitanao anio ny fandoavam-bola dia halefa ao anatin'ny daty fanaterana ny kaontinao.
Rafitra Automorika : Ny valala fanaraha-maso an-tsokosoko dia azo ampiasaina amin'ny fanaraha-maso tsiranoka amin'ny rafitra automation, toy ny tsipika famokarana automatique, fitaovana mekanika, sns, amin'ny alàlan'ny sensor, sns, sns, sns.
Ny fanaraha-maso ny tontolo iainana : ny valizy fanaraha-maso an-tsokosoko dia azo ampiasaina amin'ny rafitra fanaraha-maso ny tontolo iainana, toy ny fitrandrahana rivotra, ny rafitra HVAC, noho ny fifehezana ny mari-pana ao anaty trano, ny hamandoana, ny fikorontanan'ny rivotra, sns.
Ny toe-javatra fanaraha-maso ny valve pneumatic, mety amin'ny fampiharana rehetra, raha mila izany ianao, dia miarahaba anay, ny orinasanay dia manana vokatra hafa: Gate Valve , Ball Valve , FlowMeter , Globe Valve .
| Type | straight-through cage ball valve |
| Nominal diameter | DN15-400mm |
| Nominal pressure | PN16, 40, 64; ANSI150, 300, 600 |
| Connection form: | Flange type |
| Valve body material: | WCB, WC6, WC9, LCB, LC2, LC3, CF8, CF8M, etc. |
| Bonnet type: Standard type (P): | -17 - +230℃ |
| Gland type: | Bolt pressing type |
| Filling: | PTFE V-shaped packing, PTFE asbestos and flexible graphite |
Components valve
| Valve core form: | pressure balanced valve core |
| Adjustment characteristics: | equal percentage, linear, quick opening |
| Internal materials: | 304, 304 cladding STL, 316, 316 cladding STL, 316L, etc. |
| Bellows material: | 304L, 316L, Harbin C alloy, etc. |
| (1) Pneumatic actuator | |
| Model: | film type |
| Diaphragm material: | ethylene-propylene rubber sandwiched with nylon |
| Spring range: | 20-100KPa, 40-200KPa, 80-240KPa |
| Air supply pressure: | 140KPa, 160KPa, 280KPa, 400KPa |
| Air source connector: | Rc1/4, Rc3/8 |
| Ambient temperature: | -30 ~ +70℃ |
| Mode of action: | air-opening type (reaction), air-closing type (direct action) |
| Remarks: | |
| ① This model of large diameter or high pressure differential regulating valve can also be equipped with a straight stroke piston actuator. | |
| ② If the ambient temperature is lower than -30℃, please contact Xipai technical personnel. |
| Leakage amount: | Metal valve seat: Complies with ANSI B16.104 Level IV |
| Non-metallic valve seat: | conforms to ANSI B 16.104 Class VI |
Product Categories : Valve fanaraha-maso pneumatic
